Golf carts have become an essential mode of transportation in various settings, from golf courses to residential communities, industrial facilities, and resorts. With advancements in battery technology, lithium batteries have become the preferred choice for powering golf carts due to their higher efficiency, longer lifespan, and lighter weight compared to traditional lead-acid batteries. However, when setting up a 48V lithium battery system for your golf cart, one critical decision you need to make is whether to connect the batteries in series or parallel. Flowers Angel Co., Ltd (NEWILLING) is here to guide you through the process and help you make the right choice for your specific needs.

Understanding Series and Parallel Connections

Before diving into the pros and cons of each connection method, it’s essential to understand what series and parallel connections mean and how they differ.

Series Connection

In a series connection, the positive terminal of one battery is connected to the negative terminal of the next battery, forming a chain. The voltage of the batteries adds up, while the capacity (measured in ampere-hours, Ah) remains the same. For example, if you connect four 12V lithium batteries in series, the total voltage will be 48V (12V x 4), but the capacity will remain the same as that of a single battery.

Parallel Connection

In a parallel connection, all the positive terminals are connected together, and all the negative terminals are connected together. This configuration keeps the voltage the same as a single battery but increases the total capacity. For instance, if you connect four 12V lithium batteries in parallel, the total voltage will remain 12V, but the capacity will be the sum of the individual batteries.

Key Considerations When Choosing Between Series and Parallel Connections

Choosing between series and parallel connections depends on various factors, including the voltage requirements of your golf cart, the desired runtime, and the specific characteristics of your lithium batteries. Below, NEWILLING highlights the key considerations to help you make an informed decision.

1. Voltage Requirements

Most golf carts are designed to operate at a specific voltage, typically 36V or 48V. If your golf cart requires a 48V system, a series connection is the most straightforward way to achieve this voltage using 12V lithium batteries. By connecting four 12V batteries in series, you can easily reach the required 48V. On the other hand, a parallel connection would not meet the voltage requirement unless you use a single 48V battery or a combination of batteries with built-in voltage balancing.

2. Capacity and Runtime

The capacity of your battery system determines how long your golf cart can run on a single charge. A parallel connection increases the total capacity, allowing for longer runtime. For example, if each 12V battery has a capacity of 50Ah, connecting four batteries in parallel would result in a total capacity of 200Ah. In contrast, a series connection would maintain the capacity at 50Ah. If extended runtime is your priority, a parallel connection might be more suitable.

3. Current Handling

Parallel connections distribute the current load across multiple batteries, reducing the strain on each individual battery. This can be particularly beneficial if your golf cart requires high current for acceleration or climbing steep inclines. Series connections, however, do not distribute the current load, which can lead to increased stress on the batteries and potentially reduce their lifespan.

4. Battery Management System (BMS)

A Battery Management System (BMS) is crucial for ensuring the safety and performance of lithium batteries. When connecting batteries in series, it’s essential to use a BMS that can monitor and balance the voltage of each individual battery. This prevents overcharging or over-discharging, which can damage the batteries. In parallel connections, the BMS focuses on managing the total capacity and current distribution. NEWILLING recommends using high-quality BMS solutions compatible with your chosen connection method.

5. Maintenance and Troubleshooting

Parallel connections are generally easier to maintain and troubleshoot because each battery operates at the same voltage. If one battery fails, it’s easier to identify and replace without affecting the overall system. In series connections, a single battery failure can disrupt the entire system, making troubleshooting more challenging.

6. Weight and Space Constraints

Parallel connections typically require more physical space and wiring compared to series connections. If your golf cart has limited space for battery installation, a series connection might be more practical. However, NEWILLING offers compact and lightweight lithium battery solutions that can fit various configurations, ensuring optimal performance regardless of the connection method.

Advantages and Disadvantages of Series and Parallel Connections

Series Connection

• Advantages:
  • Easy to achieve higher voltage levels.
  • Fewer wires and connectors required.
  • Suitable for golf carts with specific voltage requirements (e.g., 48V).
• Disadvantages:
  • Does not increase total capacity or runtime.
  • Increased risk of system failure if one battery malfunctions.
  • Requires a BMS to manage individual battery voltages.

Parallel Connection

• Advantages:
  • Increases total capacity and runtime.
  • Distributes current load, reducing stress on individual batteries.
  • Easier to maintain and troubleshoot.
• Disadvantages:
  • Does not increase voltage.
  • Requires more space and wiring.
  • May require additional balancing mechanisms to ensure even charging and discharging.

Recommendations from NEWILLING

At Flowers Angel Co., Ltd (NEWILLING), we understand that every golf cart has unique requirements. That’s why we offer a wide range of lithium battery solutions designed to meet various voltage and capacity needs. Here are our recommendations:

• If your golf cart requires a 48V system and you prioritize simplicity and space efficiency, opt for a series connection with four 12V lithium batteries.
• If extended runtime and higher capacity are your priorities, consider a parallel connection with multiple batteries. Ensure that the total voltage matches your golf cart’s requirements.
• Always use a high-quality BMS to monitor and protect your battery system, regardless of the connection method.
• Consult with NEWILLING experts to determine the best configuration for your specific golf cart model and usage patterns.

Conclusion

Choosing between series and parallel connections for your 48V golf cart lithium batteries is a critical decision that impacts the performance, reliability, and lifespan of your battery system. By understanding the differences between these connection methods and considering factors such as voltage requirements, capacity, current handling, and maintenance, you can make an informed choice that meets your needs.

Flowers Angel Co., Ltd (NEWILLING) is committed to providing high-quality lithium battery solutions and expert guidance to help you optimize your golf cart’s performance. Whether you need assistance with battery selection, installation, or maintenance, our team is here to support you every step of the way. Contact us today to learn more about our products and services!
